The 60GHz radar flow meter (Model HRF 600S) is engineered for high-precision, non-contact flow measurement in complex industrial environments. Designed to meet the demands of oil & gas, wastewater treatment, chemical processing, HVAC systems, marine operations, food production, and vehicle fluid monitoring, this advanced radar-based system ensures consistent and reliable performance. Its high-frequency radar technology enables accurate flow detection even in turbulent, contaminated, or variable conditions.
Key Features
- 60GHz radar-based non-contact measurement
- High accuracy velocity and level sensing
- IP68-rated enclosure for harsh environments
- Wide operating temperature range (-35°C to +70°C)
- Multi-output communication (RS485, RS232, 4-20mA, MODBUS)
- Low maintenance and long operational lifespan
- Real-time data transmission for automation systems
Design & Functionality
This radar flow meter integrates velocity measurement and water level sensing using advanced radar frequencies. The 24GHz radar module measures surface velocity, while the 80GHz radar sensor ensures precise level detection. Together, they provide accurate flow calculations for open channels, pipelines, and industrial systems.
The non-contact design eliminates wear and tear, making it ideal for corrosive chemicals, wastewater, and high-temperature environments. Its compact and rugged construction supports installation in remote and difficult-to-access locations.
Total Crossed Beams
The system utilizes optimized radar beam propagation to ensure accurate signal reflection from fluid surfaces. This enables stable performance even in environments with foam, vapor, or debris, ensuring consistent flow monitoring across industries like wastewater and marine systems.
Beam Pitch Options
With a controlled antenna angle of 12°, the radar beam maintains focused signal transmission, improving measurement precision in narrow channels and confined industrial setups. This makes it suitable for HVAC pipelines, chemical reactors, and process control systems.
Intrinsic Synchronism
The integrated radar system ensures synchronized velocity and level measurements, enabling real-time flow calculation without signal mismatch. This intrinsic synchronism enhances reliability in automated industrial environments and supports advanced process optimization.
Operational Advantages
- Accurate flow monitoring in harsh and dynamic environments
- Reduced downtime with maintenance-free operation
- Suitable for corrosive, high-pressure, and contaminated fluids
- Seamless integration with industrial automation systems
- Enhanced efficiency in process control and fluid management
